Leuchtkörper
Montageart: Pendelmontage
Material: Stahlblech
Farbe: Weiß RAL 9003 (Andere Farben auf Anfrage)
Elektrontechnik
Betriebsgerät: LED Betriebsgerät
Netzspannung: 220 – 240 V
Netzfrequenz: 50-60 Hz
Umgebungstemperatur: -20,00 – 35,00 C°
Lichttechnik
Lampentyp: LED
Farbwiedergabe: CRI > 80
Lebensdauer: 50.000 h (L80 B10)
Ausstrahlwinkel: > 80°
Lichtverteilung: direkt 80% – indirekt 20%
Blendungsbegrenzung: UGR <19
Optisches System
OP opale Abdeckung
Prüfungen
Schutzart: IP20
Schutzklasse: I
Schlagschutz: IK02
Energieeffizienzklasse: A++ A+ A
Länderkennzeichnung: CE
Sicherheitskennzeichen: F
Glühdrahtprüfung: 650 °C – 30 s
Sonstige Kennzeichen: WEEE-Zeichen
Seilaufhängungen sind nicht im Lieferumfang enthalten (siehe Zubehör).
2133b.SA.1500/Set | Seilaufhängung für Leuchte 21133b LED / 2 Stück Y-Seilpendel, 1500 mm |
2100.DB | Universal-Deckenbaldachin;Ø83mm, Höhe 29mm |
Katalogseite
Art.-Nr. | Lichtstrom | Leistung | Farbtemp. | IP | Maße | DA Ø | Gewicht | Bruttopreis | LDT | Datenblatt | LV-Text |
---|---|---|---|---|---|---|---|---|---|---|---|
2133b.5130.MP.80d | 4400 lm | 51 W | 3000 K | IP20 | 1300 x 200 x 31 mm | - | 4.50 kg | 276.60 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.5140.MP.80 | 4630 lm | 51 W | 4000 K | IP20 | 1300 x 200 x 31 mm | - | 4.50 kg | 230.20 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.5140.MP.80d | 4630 lm | 51 W | 4000 K | IP20 | 1300 x 200 x 31 mm | - | 4.50 kg | 276.60 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.6430.MP.80 | 5800 lm | 64 W | 3000 K | IP20 | 1600 x 200 x 31 mm | - | 4.80 kg | 264.20 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.6430.MP.80d | 5800 lm | 64 W | 3000 K | IP20 | 1600 x 200 x 31 mm | - | 4.80 kg | 316.70 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.6440.MP.80 | 6000 lm | 64 W | 4000 K | IP20 | 1600 x 200 x 31 mm | - | 4.80 kg | 264.20 Euro |
LDT Download |
PDF Download |
PDF Download |
2133b.6440.MP.80d | 6000 lm | 64 W | 4000 K | IP20 | 1600 x 200 x 31 mm | - | 4.80 kg | 316.70 Euro |
LDT Download |
PDF Download |
PDF Download |
