7242

Bauform 7242


LED Industrieleuchte in einem schlichten Design.

Opale Polycarbonatabdeckung aus einem schlagzähen Polycarbonat (IK10).

Mit Lumenwerten bis zu 7280lm netto, einem Wirkungsgrad von knapp 126 lm/W und der Schutzart IP54 finden diese Leuchten überall dort ihren Einsatz, wo eine effiziente LED Beleuchtung mit guten Lichtwerten und einer hohen Schutzart benötigt wird.

Technische Daten

Leuchtkörper
Montageart: Aufbauleuchte
Material: Stahlblech
Farbe: Weiß (RAL 9003)

Elektrotechnik
Betriebsgerät: LED Betriebsgerät
Netzspannung: 220 – 240 V
Netzfrequenz: 50-60Hz
Umgebungstemperatur: -25 bis +35°C
Schlagschutz: IK10
Schutzklasse: I

Lichttechnik
Lampentyp: LED
Farbwiedergabe: CRI > 80
Lebensdauer: 50.000h (L90/B10)
Lichtverteilung: direkt strahlend

Optisches System

PC Polycarbonatabdeckung (uv-beständig)

Prüfungen
Schutzart:IP54
Energieeffizienzklasse: A++ A+ A
Länderkennzeichnung: CE
Sonstige Kennzeichen: WEEE-Zeichen

Downloads

Katalogseite

Bauform 7242

Zubehör



Art.-Nr. Lichtstrom Leistung Farbtemp. IP Maße DA Ø Gewicht Bruttopreis LDT Datenblatt LV-Text
7242.1830.PC.80 2128 lm 18 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 86.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.1830.PC.80d 2128 lm 18 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 126.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.1840.PC.80 2240 lm 18 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 86.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.1840.PC.80d 2240 lm 18 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 126.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.2230.PC.80 2584 lm 22 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 86.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.2230.PC.80d 2584 lm 22 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 126.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.2240.PC.80 2720 lm 22 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 86.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.2240.PC.80d 2720 lm 22 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 126.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.3030.PC.80 3534 lm 30 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 92.40 Euro LDT
Download
PDF
Download
PDF
Download
7242.3030.PC.80d 3534 lm 30 W 3000 K IP54 1160 x 109 x 85 mm - 1.90 kg 127.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.3040.PC.80 3720 lm 30 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 92.40 Euro LDT
Download
PDF
Download
PDF
Download
7242.3040.PC.80d 3720 lm 30 W 4000 K IP54 1160 x 109 x 85 mm - 1.90 kg 127.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.3530.PC.80 4114 lm 35 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 106.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.3530.PC.80d 4114 lm 35 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 139.80 Euro LDT
Download
PDF
Download
PDF
Download
7242.3540.PC.80 4330 lm 35 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 106.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.3540.PC.80d 4330 lm 35 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 139.80 Euro LDT
Download
PDF
Download
PDF
Download
7242.4230.PC.80 4950 lm 42 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 106.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.4230.PC.80d 4950 lm 42 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 139.80 Euro LDT
Download
PDF
Download
PDF
Download
7242.4240.PC.80 5210 lm 42 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 106.20 Euro LDT
Download
PDF
Download
PDF
Download
7242.4240.PC.80d 5210 lm 42 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 139.80 Euro LDT
Download
PDF
Download
PDF
Download
7242.5830.PC.80 6916 lm 58 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 118.00 Euro LDT
Download
PDF
Download
PDF
Download
7242.5830.PC.80d 6916 lm 58 W 3000 K IP54 1160 x 159 x 85 mm - 2.50 kg 151.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.5840.PC.80 7280 lm 58 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 118.00 Euro LDT
Download
PDF
Download
PDF
Download
7242.5840.PC.80d 7280 lm 58 W 4000 K IP54 1160 x 159 x 85 mm - 2.50 kg 151.30 Euro LDT
Download
PDF
Download
PDF
Download
7242.MW40.PC1.80 2250-3720 lm - 4000 K IP54 1160 x 109 x 85 mm - 1.9 kg 72.20 Euro LDT anfordern PDF
Download
-
7242.MW40.PC2.80 4000- 7280 lm - 4000 K IP54 1160 x 159 x 85 mm - 2.8 kg 97.50 Euro LDT anfordern PDF
Download
-
Bruttopreise exkl. Mehrwertsteuer
